JT-2000A Film Wrapping Machine

JT-2000A Film Wrapping Machine 1. Max. package height :2100 mm 2. Table height :650 mm 3. Turntable speed: 0-13 r/min4. Turntable speed: 0-13 r/min (adjustable)5. Turntable diameter:φ1500 6. Air supply: 5-6.5kg/cm2 7. Film size : ID : 76, OD : max 350 8. Automatic clumping and cutting system 9. Turntable : motor driving system with heavy duty bearing 10. Pre-stretch system : 250% 11 Power: 380V, 3 phase,50Hz 12 Film frame vertical speed :03.5m/min 13. Others: Control mode: PLC + Transducer + Touch screen+ standard control button + signal switch, self-service/self-motion/manual control three control pattern Packing circles of superstratum and under layer are separately controlled by their own counter. Mid-strengthen-function design, any parts can be strengthened Double deck packing pattern, free design the film overlapping degree upon the different packing requirements. Pre-stretch motor film frame design, gear box system and transducer control the tension together, greatly save the packing material, make better packing effect. Auto photoelectricity measure height & turn table location. Turntable speed &film frame vertical speed are controlled by transducer, stepless speed changing. Set drive roller conveyor on turn table. PLC: MITSUBISHI Transducer: DELTA Motor: Made in TAIWAN
